[available only in limited areas] M900 series equipped with Direct Drive Motor

[available only in limited areas] M900 series equipped with Direct Drive Motor

  • ECONOMY TYPE
  • Bottom feed

Overedger & safety stitch machines

[available only in limited areas] M900 series equipped with Direct Drive Motor

  • M932(/D222) : Safety stitch machines
  • M952(/D222) : Overedgers
  • M922(/D222) : double chainstitch machine

M932(/D222) : Safety stitch machines

Subclasses Use Maximum speed Seam
M932-38-3x4(/D222) ・[Use]Plain seaming ・[Maximum speed]7,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 2-needls 5-threads, safety stitch (plain seaming)
M932-70-5x5(/D222) ・[Use]Plain seaming ・[Maximum speed]7,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 2-needls 5-threads, safety stitch (plain seaming)
M932-86-5x6(/D222) ・[Use]Plain seaming ・[Maximum speed]5,500 sti/min
  • ・[Seam]
  • 2-needls 5-threads, safety stitch (plain seaming)
M932-48-3x4(/D222) ・[Use]Shirring ・[Maximum speed]5,500 sti/min
  • ・[Seam]
  • 2-needls 5-threads, safety stitch (shirring)  *Pleats are made with differential feed
M932-48P2-3x4(/D222) ・[Use]Shirring while piping ・[Maximum speed]5,000 sti/min
  • ・[Seam]
  • 2-needls 5-threads, safety stitch (shirring while piping)
M932-355-3x2x4(/D222) ・[Use]3-needle versatile machine for plain seaming ・[Maximum speed]6,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 3-needls 6-threads, safety stitch (plain seaming)
M932-551-5x2.5x3.5(/D222) ・[Use]Attaching U-shaped tape ・[Maximum speed]6,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 3-needls 6-threads, safety stitch (plain seaming)

M952(/D222) : Overedgers

Subclasses Use Maximum speed Seam
M952-01-4(/D222) ・[Use]Blindstitch hemming ・[Maximum speed]7,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 1-needle 3-threads, overedge (Blindstitch hemming)
M952-17-4(/D222) ・[Use]Plain seaming ・[Maximum speed]7,000 (5500 with DDM) sti/min
  • ・[Seam]
  • 1-needle 3-threads, overedge (plain seaming)
M952-13-2x4(/D222) ・[Use]Plain seaming ・[Maximum speed]7,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 2-needls 4-threads, overedge (plain seaming)
M952-13-2x5(/D222) ・[Use]Plain seaming ・[Maximum speed]7,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 2-needls 4-threads, overedge (plain seaming)
M952-13H-2x4(/D222) ・[Use]Plain seaming ・[Maximum speed]6,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 2-needls 4-threads, overedge (plain seaming)
M952-13H-2x5(/D222) ・[Use]Plain seaming ・[Maximum speed]6,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 2-needls 4-threads, overedge (plain seaming)
M952-13H-2x7(/D222) ・[Use]Plain seaming ・[Maximum speed]6,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 2-needls 4-threads, overedge (plain seaming)
M952-52-2x4(/D222) ・[Use]Plain seaming ・[Maximum speed]7,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 2-needls 4-threads, overedge (plain seaming)
M952-52-2x5(/D222) ・[Use]Plain seaming ・[Maximum speed]7,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 2-needls 4-threads, overedge (plain seaming)
M952-23B-2.5x4.5(/D222) ・[Use]Plain seaming ・[Maximum speed]6,500 (5,500 with DDM) sti/min
  • ・[Seam]
  • 2-needls 4-threads, overedge (plain seaming)
M952-16S2-1.5(/D222) ・[Use]Turn down hemming ・[Maximum speed]7,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 1-needls 3-threads, overedge (Turn down hemming)
M952-180-4(/D222) ・[Use]Backlatching ・[Maximum speed]7,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 1-needls 3-threads, overedge (Backlatching)
M952-181-2x4(/D222) ・[Use]Backlatching ・[Maximum speed]7,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 2-needls 4-threads, overedge (Backlatching)
M952-90-6(/D222) ・[Use]Butt-end sewing ・[Maximum speed]5,000 sti/min
  • ・[Seam]
  • 1-needle 2-threads, overedge (Butt-end sewing)

M922(/D222) : double chainstitch machine

Subclasses Use Maximum speed Seam
M922-02x250-24(/D222) ・[Use]Attaching tape ・[Maximum speed]6,000 (5,500 with DDM) sti/min
  • ・[Seam]
  • 2-needles, double chainstitch (attaching tape)
